C6X jaw crusher with large feed opening

Don't hesitate any longer, submit your inquiry now, let the C6X jaw crusher inject powerful power into your production line and open a new chapter of efficiency and profitability!
Zhengzhou MiningAlliance Machinery Co.,LTD. Henan, China
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/66cfd7603dfc4b7004f304ac/66d56c26c70a712e82152eb9/20240905150546/C6X%20Jaw%20Crusher%20(2).jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/66cfd7603dfc4b7004f304ac/66d56c26c70a712e82152eb9/20240905150546/C6X%20Jaw%20Crusher%20(1).jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/66cfd7603dfc4b7004f304ac/66d56c26c70a712e82152eb9/20240905150546/C6X%20Jaw%20Crusher%20(3).jpg
https://shmuker.oss-cn-hangzhou.aliyuncs.com/data/oss/66cfd7603dfc4b7004f304ac/66d56c26c70a712e82152eb9/20240905150546/C6X%20Jaw%20Crusher%20(4).jpg

Recommended Products

Product Parameters
Feed port size (mm)
C6X80: 520×800
C6X100: 760×1000
C6X110: 850×1100
C6X125: 950×1250
C6X145: 1100×1450
C6X160: 1200×1600
C6X200: 1500×2000
See more
Maximum feed size (mm)
C6X80: 420
C6X100: 630
C6X110: 720
C6X125: 800
C6X145: 920
C6X160: 1020
C6X200: 1200
Discharge port adjustment range (mm)
C6X80: 60-150
C6X100: 70-175
C6X110: 80-200
C6X125: 100-250
C6X145: 125-275
C6X160: 150-300
C6X200: 175-300
Production capacity (tons/hour)
C6X80: 80-290
C6X100: 130-420
C6X110: 160-550
C6X125: 230-760
C6X145: 320-950
C6X160: 410-1150
C6X200: 610-1510
Speed ​​(rpm)
C6X80: 350
C6X100: 260
C6X110: 230
C6X125: 220
C6X145: 220
C6X160: 220
C6X200: 200
Power (kW)
C6X80: 75
C6X100: 110
C6X110: 160
C6X125: 160
C6X145: 200
C6X160: 250
C6X200: 400
Dimensions (mm)
C6X80: 2650×1540×1780
C6X100: 3700×2440×2520
C6X110: 3800×2450×2550
C6X125: 4100×2750×2780
C6X145: 4400×3060×3210
C6X160: 5700×3650×3550
C6X200: 6500×3990×4260
Feed port size (mm)
C6X80: 520×800
C6X100: 760×1000
C6X110: 850×1100
C6X125: 950×1250
C6X145: 1100×1450
C6X160: 1200×1600
C6X200: 1500×2000
Close
Product Details
Product Introduction
With 30 years of industry experience, Zhengzhou MiningAliance Machinery Co., Ltd. (MiningAliance) has carefully built the C6X jaw crusher for global customers. This crusher combines modern advanced technology and is designed for high-volume aggregate plants. It has a large feed opening size and can efficiently handle a variety of ores to meet large-scale production needs. In terms of structural design, it overcomes the problems of low production efficiency and difficult installation and maintenance of traditional jaw crushers, and is an ideal coarse crushing equipment. The company uses high-quality materials and advanced technology to continuously promote the development of machine technology and ensure long-term and stable returns on investment for customers. In markets such as Southeast Asia, the Middle East, and Africa, the C6X jaw crusher has performed excellently and can help customers improve production line efficiency and profit returns. Choosing it will give you a competitive advantage brought by technological progress.
Advantages and features
1. Combining modern advanced technology, specially designed for high-capacity aggregate plants.
2. The feed port is large in size and can process a variety of ores efficiently.
3. Overcome the problems of low production efficiency and difficult installation and maintenance of traditional jaw crushers.
4. Use high-quality materials and advanced technology to ensure long-term and stable investment returns.
Application Scenario
C6X jaw crusher is suitable for large-scale production in aggregate plants. In international trade, it is suitable for customers in Southeast Asia, the Middle East, Africa and other markets, and can provide efficient coarse crushing solutions for both ore processing companies and related production line projects.
Corporate Information
Zhengzhou MiningAlliance Machinery Co.,LTD.
99%
On-time delivery rate
Less than 3 hours
Response time
1.2 million square meters
Construction area
Service Guarantee
Service Information
Address
No. 12, Jingguang Middle Road, Erqi District, Zhengzhou City, Henan Province
Advisory Message
Pre-sales advice
1. Contact number: For more product information and service details, please call our customer service hotline +8613849049686.
2. Email: You are welcome to send an email to [email protected] and we will respond to your inquiries and needs as soon as possible.
After-sales service
We have 62 professional after-sales engineers who can meet the emergency response requirements when equipment fails, ensuring that all problems with global equipment are professionally answered and handled within 24 hours.
proposed price
Please contact us for the latest quotation
Product Specifications Reference
Input size
0-1280mm
Capacity
160-1510TPH
Model
C6X80 C6X100 C6X110 C6X125 C6X145 C6X160 C6X200
